ultracapacitor battery super capacitor 5.5v 1.0f

Quick Details

• Place of Origin: Shandong, China (Mainland)
• Brand Name: Enerise
• Model Number: 5.5v 1.0f
• Type: Super Capacitor
• Application: General Purpose
• Package Type: Blister/Carton
• Capacitance:0.1F0.22F,0.33F,0.47F,1.0F,1.5F Ultracapacito
• Rated Voltage: 5.5V
• Operating Temperature: -20~70C

Packaging & Delivery

Packaging Details:	Common Carton /According to your requirements
Delivery Detail:	one week after deposit

Specifications

1.High Energy Density
2.High Power Density
3.Environment Friendly
4.Delivery is fast

Specifications

Electric double layer super capacitor 5.5V 1F , ultra high capacitance capacitor , V type ,H type , C type ultra

Shandong Enerise Power Technology Co., Limited offers a wide range of ultracapacitor for used in computer ,telphone , digital radios etc .





5.5V1 F-C



Materials issue: SC5R5105Z-C



Voltage: 5.5V



Capacity: 1F



Weight: 3.2g



Product size: D20*H12.5 (P5mm)



Resistance values: <75Ω;



Operating temperatures: -25 to70°C



Cycle life: Standard change-discharge mode>100000 cycles











No.	Testing Items		Criteria	Testing Methods
1.1	Rated voltage(V)		5.5V
1.2	Rated discharge capacitance		1.0F	Standard charge model, then discharge to 0.1V at rated current; Repeat 20 time
1.3	Capacitance tolerance		-20%~+80%
1.4	Max. work voltage		6.0V
1.5	Nominal impedance	AC Imp	25Ω
		DC Imp	40Ω
1.6	Work temperature range		-25~70°C
1.7	Storage temperature range		-40~85°C
